| Model：LH-RJ45/05-4-24 D (POE) | LH | Lightning pick surge protector |
| RJ45 | RJ45 interface surge protector | |
| 5 | Rated voltage: 5, 12, 24V~ | |
| 4 | 4:4 pass; 8:8 pass | |
| 24 | Number of interfaces | |
| D | Default: no power protection module; D: power protection module | |
| POE | Default: conventional product; POE: support POE equipment |
| Model | LH-RJ45/05 | LH-RJ45/12 | LH-RJ45/24 | POE parameter |
| Maximum continuous working voltage Uc | 6.5V | 15V | 30V | 60V |
| Nominal discharge current (8/20μS) In | 3KA | 3KA | 3KA | 5KA |
| Rated voltage Un | 5V | 12V | 24V | 48V |
| Rated current I | 1A | 1A | 1A | 1A |
| Insertion loss | ≤0.5dB | ≤0.5dB | ≤0.5dB | / |
| working environment | -40 ℃~+85℃ | |||
| Relative humidity | ≤95％（25℃） | |||
| Shell color | Off-white, yellow | |||
| illustrate | 4-way products are suitable for 10M/100M networks; 8-way products are suitable for 100M/1000M networks | |||
